l Min. and max. temperature 2)
Pointer
In this menu item, the device status is displayed. If the sensor detects
a fault, "OK" will be displayed. If a fault is detected, a flashing failure
message is outputted sensor-specifically, e.g. "E013". The fault is also
displayed in clear text, e.g. "No measurement value".
Information:
The fault message as well as the clear text indication are also carried
out in the measured value display.
Meas. reliability
Sensor status
Available with the trend curve:
l "X -Zoom": Resolution in minutes, hours or days
l "S top/Start": Interrupt a recording or start a new recording
l "U nzoom": Reset the resolution to minutes
Trend curve
Menu section, service
In this menu item you simulate a user-defined level or pressure value
via the current output. This allows you to test the signal path, e.g.
through connected indicating instruments or the input card of the
control system.
The following simulation variables are available:
l Percent
l Current
l Pressure
With Profibus PA sensors, the selection of the simulated value is made
via the "Channel" in the menu "Basic adjustments".
How to start the simulation:
2) Temperature: -50 … +150 °C.
Sensor status
Curve presentation
Simulation of
measured val-
ues
14 Indicating and adjustment module for IPT-1* sensors
5 Set up
