The linearization curve creates a correlation between height and
volume. It takes into account the vessel geometry for the displayed
measured value and current output.
Factory setting is linear.
Linearisation curve
linear
In the menu item "Sensor-TAG" you edit a 12-digit measurement loop
name. An unambiguous designation can hence be assigned to the
sensor, e.g. the measurement loop name or the tank or product
designation. In digital systems and in the documentation of larger
plants, a singular designation should be entered for exact identification
of individual measuring sites.
The available digits comprise:
l Letters from A … Z
l Numbers from 0 … 9
l Special characters +, -, /, -
Factory setting is "Sensor".
Sensor-TAG
Sensor
Menu section, display
An integrated background lighting can be switched via the adjustment
menu. The following version is necessary:
l Indicating and adjustment module …- 01 or higher
l Sensor electronics 4 … 20 mA …- 01 or higher
l Sensor electronics pressure transmitter 4 … 20 mA …- 02 or
higher
l Sensor electronics Profibus PA or Foundation Fieldbus …- 03 or
higher
The version is stated on the type label of the indicating and adjustment
module or the sensor electronics. The function depends also on the
height of the supply voltage, see operating instructions manual of the
respective sensor.
In the default setting, the lightning is switched off.
Min. and max. measured values are saved in the sensor. The values
are displayed in the menu item "Peak values".
l Min. and max. pressure 1)
1) Pressure: -50 … +150 % of the nominal measuring range.
Edit sensor TAG
Lighting
Pointer
Indicating and adjustment module for IPT-1* sensors 13
