IPT-1* - front-flush connection, part 2
5
1
mm
(2
1
/ 6
4
")
ø 84 mm (3 5 / 16
")
RT RA SA
ø64 mm
(2 33 /
64
")
8
2
mm
(3
1
5
/ 6
4
")
3T 3R
ø 65 mm (2 9 /
16
")
ø 84 mm (3 5 /
16
")
ø 105 mm (4 9 /
64
")
8
2
mm
(3
1
5
/ 6
4
")
ø50 mm
(1 31 / 32
")
8
2
mm
(3
1
5
/ 6
4
")
8
1
m
m
(3
3
/ 16
")
ø 74 mm (2 29 / 32
")
Fig. 25: IPT-1* - SA = Tri-Clamp 2", RA = bolting DN 40/PN 40 according to DIN 11851, RT = Tri-Clamp 1½", 3T =
DRD, 3R = Varivent Form F
Process pressure transmitter IPT-1* Vers. 3.0 - metalic sensor • 4 … 20 mA/HART 53
