Nominal range Overload, max. pressure Overload, min. pressure
0 … 16 bar/0 … 1.6 MPa 80 bar/8 MPa -1 bar/-100 kPa
0 … 40 bar/0 … 4 MPa 80 bar/8 MPa -1 bar/-100 kPa
0 … 100 bar/0 … 10 MPa 200 bar/20 MPa -1 bar/-100 kPa
0 … 250 bar/0 … 25 MPa 500 bar/50 MPa -1 bar/-100 kPa
0 … 600 bar/0 … 60 MPa 1200 bar/120 MPa -1 bar/-100 kPa
-1 … 3 bar/-100 … 300 kPa 17 bar/1700 kPa -1 bar/-100 kPa
-1 … 5 bar/-100 … 500 kPa 35 bar/3500 kPa -1 bar/-100 kPa
-1 … 15 bar/-100 … 1.5 MPa 80 bar/8 MPa -1 bar/-100 kPa
Absolute pressure
0 … 0.4 bar/0 … 40 kPa 2 bar/200 kPa 0 bar abs.
0 … 1.6 bar/0 … 160 kPa 10 bar/1000 kPa 0 bar abs.
0 … 6 bar/0 … 600 kPa 35 bar/3500 kPa 0 bar abs.
0 … 16 bar/0 … 1.6 MPa 80 bar/8 MPa 0 bar abs.
Reference conditions and actuating variables (similar to DIN EN 60770-1)
Reference conditions according to DIN EN 61298-1
-
Temperature + 18 … +30 °C (+64 … +86 °F)
-
Relative humidity 45 … 75 %
-
Air pressure 860 … 1060 mbar/86 … 106 kPa (12.5 … 15.4 psig)
Determination of characteristics Limit point adjustment according to IEC 61298-2
Characteristics linear
Reference installation position upright, diaphragm points downward
Influence of the installation position depending on the isolating diaphragm version
Deviation determined according to the limit point method according to IEC 60770 12 )
Applies to digital interfaces (HART, Profibus PA, Foundation Fieldbus) as well as to analogue
current output 4 … 20 mA. Specifications refer to the set span. Turn down (TD) is the relation
nominal measuring range/set span.
Deviation for measuring ranges 0.4 … 1000 bar
-
Turn down 1 : 1 up to 5 : 1 < 0.1 %
-
Turn down > 5 : 1 < 0.02 % x TD
Deviation for measuring ranges > 1000 bar
-
Turn down 1 : 1 up to 2 : 1 < 0.6 %
Deviation with absolute pressure measuring range 0.1 bar
-
Turn down 1 : 1 up to 5 : 1 < 0.25 %
-
Turn down > 5 : 1 < 0.05 % x TD
12) Incl. non-linearity, hysteresis and non-repeatability.
Process pressure transmitter IPT-1* Vers. 3.0 - metalic sensor • 4 … 20 mA/HART 45
