TP-141, TP-142 - Connecting the TP-141, TP-142 9
4 Connecting the TP-141, TP-142
Always switch off the power to each device before connecting it to your
TP-141, TP-142. After connecting your TP-141, TP-142, connect its
power and then switch on the power to each device.
You can use the TP-141 and TP-142 to configure an XGA / Audio Line-to-Twisted Pair
Transmitter and Receiver system.
To connect the TP-141 XGA/Audio Line Transmitter with the TP-142 XGA/Audio
Line Receiver, as illustrated in Figure 3 , do the following:
1. On the TP-141, connect the XGA source (for example, the graphics card of a
laptop) to the XGA INPUT 15-pin HD (F) connector.
2. Connect an audio source to the AUDIO IN 3.5mm mini jack, for example,
using a Kramer C-GMA/GMA cable (VGA 15-pin HD (M) +audio jack to VGA
15-pin HD (M) +audio jack).
Alternatively, you can connect an XGA source to the XGA INPUT 15-pin HD
(F) connector, and a separate audio source to the AUDIO IN 3.5mm mini
jack.
Cables are not supplied. The complete list of Kramer cables is on our Web site at
http://www.kramerelectronics.com
3. On the TP-142, connect the XGA OUT 15-pin HD (F) connector to the XGA
acceptor (for example, a display).
4. Connect the AUDIO OUT S/PDIF RCA connector to the digital audio
acceptor (for example, an AV receiver).
5. Connect the ANALOG 3.5mm mini jack to the analog audio acceptor (for
example, a stereo audio recorder).
6. Connect the LINE OUTPUT RJ-45 connector on the TP-141 to the LINE IN
RJ-45 connector on the TP-142, via CAT 5 (UTP or STP) cabling, (see
connector pinouts in Section
4.1
).
7. Connect the 12V DC power adapter to the power socket of either the TP-141
or the TP-142 and connect the adapter to the mains electricity. The Power
Connect feature feeds power to the second device. If the second device
does not power on due to a long line, connect a 12V DC power adapter to
the second device as well.
i
