4 PT-571/PT-572+ - Overview
3 Overview
The PT-571 is a DGKat ™ twisted pair transmitter for HDMI signals. The PT-571
converts an HDMI signal to a single twisted pair signal and the PT-572+ converts
the twisted pair signal back to an HDMI signal.
The HDMI Line Transmitter/Receiver system features:

Maximum data rate 4.95Gbps (1.65Gbps per graphic channel)

HDTV compatibility

HDCP compliance

HDMI support

EDID PassThru that passes EDID signals between the source and display

3D pass-through

System Range – Up to 90m (295ft) at 1080i, or up to 30m (98ft) at 1080p on
shielded BC-DGKat524 cable; 90m (295ft) at 1080i, or up to 70m (230ft) at
1080p on shielded BC-DGKat623 cable; 100m (330ft) at 1080i or up to 90m
(295ft) at 1080p on shielded BC-DGKat7a23 cable
Note that the transmission range depends on the signal resolution, graphics card and
display used. The distance using non-Kramer CAT 5, CAT 6 and CAT 7a cables may not
reach these ranges
 DGKat™ Signal Integration – Kramer’s unique technology for converting
TMDS as well as control and communication to signals that run over twisted
pair cables
 Power Connect™ that feeds 12V DC over the CAT 5 cable from transmitter
to receiver (see Section
3.2
)

Ultra-Compact Pico
TOOLS™ – 4 units can be rack mounted side−by−side
in a 1U rack space with the optional RK−4PT rack adapter.
Use only shielded cable where both ends of the shield are soldered
to ground to eliminate ESD interface.
