616T, 616R - Technical Specifications

Technical Specifications

INPUTS:

DVI IN (616T), 1 duplex multimode fiber optic with 2 LC

connectors (616R)

OUTPUTS:

1 duplex multimode fiber optic with 2 LC connectors

(616T), DVI OUT (616R)

RESOLUTION:

13.5Gbps (2.25Gbps bandwidth per graphic channel)

WQUXGA, 33Hz (XGA is not supported)

MAX. RANGE:

500m (1640ft) for WQUXGA (3840x2400) at 33Hz refresh

rate.

POWER CONSUMPTION:

5V DC, 430mA max. (616T); 350mA max. (616R)

OPERATING TEMPERATURE:

0° to +40°C (32° to 104°F)

STORAGE TEMPERATURE:

-40° to +70°C (-40° to 158°F)

HUMIDITY:

10% to 85%, RHL non-condensing

DIMENSIONS:

3.9 cm x 7.2 cm x 1.5 cm (1.5" x 2.8" x 0.75") W, D, H

WEIGHT:

0.14kg (0.31lbs) approx.

ACCESSORIES:

2 power supplies: 5V DC/1A

OPTIONS:

C-2LC/2LC 2 LC fiber optic cable

Specifications are subject to change without notice at
