6

6810HDxl - Connecting the 6810HDxl

4

Connecting the 6810HDxl

Always switch off the power to each device before connecting it to your
6810HDxl. After connecting your 6810HDxl, connect its power and

then switch on the power to each device.

To connect the 6810HDxl , as illustrated in the example in

Figure 2

, do the

following:

1. Connect an SD/HD/3G HD-SDI source (such as, an HD/SD digital video

player) to the SDI IN BNC connector.

2. Connect the SDI OUT BNC connector to an SDI and AES/id3 acceptor (such

as, video broadcast equipment).

3. Connect an AES digital audio source (such as, DAT Player 4) to the AUDIO IN

TO EMBEDDER 4 BNC connector (for channel 4).

4. Connect the AUDIO OUT TO DE-EMBEDDER BNC connector (for channel 1)

to an AES digital audio acceptor (such as, DAT Recorder 1).

5. Connect the SDI LOOP BNC connector to an SDI acceptor (such as, an SDI

display).

6. Connect the 5V DC power adapter to the power socket and connect the

adapter to the mains electricity (not shown in

Figure 2

).

i
