Kramer Electronics XE-21SA - Manual

P/N: 2900-000913
Your XE-21SA 2x1 s-Video / Audio Switcher
Congratulations on purchasing your XE-21SA, which is intended for CCTV, editing systems,
and any application where a passive “hard-wired” signal path is preferred. Your XE-21SA is a
high quality mechanical, passive 2x1 s Video / Audio Switcher that can switch one of two
s-Video and audio input signals to an s-Video and audio output.
Connecting the XE-21SA 2x1 s-Video / Audio Switcher
To setup your XE-21SA, connect:
1. Up to two s-Video sources (for example, s-Video players) to the s-Video input 4-PIN
connectors and to the appropriate audio input RCA connectors.
2. The s-Video output 4-PIN connector and the audio output RCA connectors to an
acceptor (for example, an s-Video recorder).
Note:
Use good quality connection cables to avoid interference, deterioration in signal quality due to poor matching, and elevated noise
levels (often associated with low quality cables) and position your product away from moisture, excessive sunlight and dust.
Caution – No operator-serviceable parts inside unit.
For assistance, contact your dealer. Product Warranty is for one year.
