4 6810HDxl - Overview
3 Overview
The Kramer 6810HDxl SDI/HD-SDI/3G Audio Embedder/De-embedder is a
broadcast quality audio embedder and de-embedder (it embeds and de-embeds
simultaneously) for serial digital video.
The 6810HDxl features:

A maximum data rate of 3Gpbs

1 SDI video and 4 AES/3id inputs

1 SDI video and 4 AES/3id outputs

1 looping video input

Multi-standard operation:
SDI (SMPTE 259M and SMPTE 344M), HD−SDI
(SMPTE 292M) and 3G HD−SDI (SMPTE 424M)

Group select buttons to choose the group to embed into or de-embed from
each channel pair

Kramer Equalization &
reKlocking™ Technology that rebuilds the digital
signal to travel longer distances

Status indicators: audio group detect, embed/de-embed group select, and
SD/HD lock

5V DC power
3.1 Defining the 6810HDxl SDI/HD-SDI/3G Audio
Embedder/De-embedder
This section defines the 6810HDxl.
