6810HDxl - Technical Specifications
9
6
Technical Specifications
INPUTS:
1 SD/HD/3G HD−SDI with loop (SMPTE 259M, 344M,
292M, 424M), 4 AES/3id all on BNC connectors
OUTPUTS:
1 SD/HD/3G HD−SDI (SMPTE 259M, 344M, 292M,
424M), 4 AES/3id on BNC connectors
SAMPLE RATE CONVERSION:
48kHz
POWER CONSUMPTION:
5V DC, 1.04A
OPERATING TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS
21.5cm x 16.3cm x 4.4cm (8.6" x 7" x 1.8") W, D, H
WEIGHT:
1.1kg (2.4lbs)
ACCESSORIES:
Power supply
OPTIONS:
RK-
1 19” rack adapter
Specifications are subject to change without noti
