Technical Specifications
9
7 Technical Specifications
Table 3 includes the technical specifications of the
6809HD SDI-AES
Embedder:
Table 3: Technical specifications
1
of the 6809HD SDI-AES Embedder
INPUTS:
1 x SDI, 2 x AES-3id on BNC Connectors
OUTPUT:
1 x SDI on a BNC Connector
CONTROLS:
Group select
POWER SOURCE: 12 VDC, 450mA
DIMENSIONS:
12cm x 6.95cm x 2.44cm (4.7" x 2.74" x 0.96"), W, D, H
WEIGHT:
0.3kg. (0.66lbs.)
ACCESSORIES:
Power supply, mounting bracket
OPTIONS:
19” rack adapters
1 Specifications are subject to change without notice
