4 SPK-W511 - Installing the SPK-W511
4 Installing the SPK-W511
This section explains how to:
• Choose the best location for your speakers (see Section 4.1 )
• Install the speaker wires (see Section 4.2 )
• Install the mounting brackets (see Section 4.3 )
• Install the SPK-W511 (see Section 4.4 )
4.1 Choosing the Best Location
Before installing the speakers:
• Experiment by placing the speakers in different locations before finally
deciding on the most suitable location
• Be sure that the wall type is appropriate for the mounting brackets, that is,
either solid wood, bricks, concrete, hollow building blocks, or wood studs
• Check that the mounting location is free of obstructions, such as electrical
piping, AC ducts or water lines, and so on
4.2 Installing the Speaker Wires
To install the speakers, do the following:
1. Measure the length from each speaker to the receiver, and cut the wires
accordingly, adding some access wire length to let you easily remove the
speakers from the bracket without having to disconnect the input wires.
The distance should measure up to about 4 meters (13 feet)
2. Strip the ends of the wires approximately 3/8 inch.
3. Pass the speaker wires through the round hole in the mounting bracket.
4. Unscrew the negative (black) screw-type connector, insert the wire from the
negative terminal on the receiver, and retighten.
5. Unscrew the positive (red) screw-type connector, insert the wire from the
positive terminal on the receiver, and retighten.
