SPK-W511 - Overview 3
3 Overview
The SPK-W511 includes a pair of high performance speakers that can be
mounted on the wall vertically or horizontally, and indoors as well as outdoors. The
mounting brackets are made of painted steel that can be attached to each
speaker, letting you rotate each speaker to the left or right.
The speakers are weather resistant but not waterproof, and can
withstand the humidity in the air. We recommend that you locate
them in an area that is covered and protected from rain.
3.1 Defining the SPK-W511
This section defines the SPK-W511:
Figure 1: SPK-W511
# Feature Function
1 Speaker Grille Do not remove from the speakers
2 Bracket Knob (4) Use two knobs to fasten the bracket to the speaker
3 Speaker Bracket Used for mounting the speaker onto the wall
4 Screw Type
Input Port
Positive (red) Connect to the positive stereo analog audio output
of the receiver
5 Negative (black) Connect to the negative stereo analog audio output
of the receiver
i
