SPK-W511 - Technical Specifications
7
5
Technical Specifications
Audio and Power
DESCRIPTION:
2-way on-wall speakers
FREQUENCY RESPONSE:
70Hz to 20kHz@ -10dB
WOOFER:
5.25” (133mm) polypropylene cone
TWEETER:
0.51” (13mm) Mylar
IMPEDANCE:
8Ω
NOMINAL SENSITIVITY:
89dB 1W @1M
DIRECTIVITY FACTOR (Q):
3.3 (2kHz)
DIRECTIVITY INDEX (DI)
5.2dB (2kHz)
POWER CAPACITY:
30W RMS
80W continuous program
CROSSOVER FREQUENCY:
WOOFER: Full range
TWEETER: High-pass @ 8kHz
INPUT CONNECTORS:
Gold-plated 5-way binding posts
Shipping and Installation
MATERIALS:
Frame, grill and brackets steel; cabinet ABS
OPERATING TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
WEIGHT PER SINGLE SPEAKER:
2kg (4.4lbs) approx.
WEIGHT WITH MOUNTING KIT:
2.4kg (5.3lbs) approx.
SHIPPING WEIGHT (FOR PAIR):
4.8kg (10.6lbs) approx.
DIMENSIONS:
18.5cm x 16.5cm x 24.9cm (7.28” x 6.5” x 9.8”), W, D, H.
DIMENSIONS with mounting
brackets:
18.5cm x 16.7cm x 27cm (7.28” x 6.6” x 10.6”), W, D, H.
INSTALLATION CLEARANCE:
Front panel to wall (with mounting bracket): 21cm (8.2”)
Back panel to wall (with mounting bracket): 4.5cm (1.8”)
ACCESSORIES:
2 mounting brackets (including 4 knobs and 4 mounting
screws)
OPTIONS:
BCP-2S speaker cable
COLORS:
Available in white or black
Specifications are within a 10% tolerance and are subject to change without notice at
