Getting Started
2
2 Getting Started
We recommend that you:
Review the contents of this user manual
Use Kramer high performance high resolution cables 1
A special CONFIG cable 2 is required to configure and perform firmware
upgrades to the machine
3 Overview
The RC-7RL / RC-7RLE is a highly versatile controller interface panel for
the control of A/V equipment in any multimedia room, especially the control
of a projector or other display device, via RS-232 and/or IR emitter cable.
The RC-7RL / RC-7RLE is 12V DC fed. The RC-7RL is a one-gang wall
plate. The RC-7RLE is two-gang wall plate intended for the European
market.
In particular, the
RC-7RL / RC-7RLE features:
Four configurable backlit control buttons and three signal source
buttons, each of which can be programmed 3 to carry out up to 4 macros
of 15 commands
A 3.5mm jack on the front panel for configuration
An IR learner on the front panel for the customized control of external
sources, absorbing the IR commands from different remote transmitters
In addition, the RC-7RL / RC-7RLE includes:
Two IR ports
Two RS-232 serial ports for universal display
An RS-485 serial port
Four relays for the simplified and centralized control of room functions
(such as lighting, closing blinds, projector lift, and so on)
Control via the front panel buttons
1 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com
2 C-A35M/D9F-6
3 To be configured by the system integrator only
