Site-CTRL
7
2.3.1 The Event Log Tab
The Event Log tab lists the controlled room events. The Filter area lets you
filter the information displayed.
Figure 9 and Table 3 define the Event Log
tab:
Figure 9: The Event Log Tab
Table 3: The Event Log Features
Features Function
Filter area:
Date from/Date to: set the time frame for the list
Severity: filter the severity you want displayed
IP: set the IP number you want displayed
Group: set the name group you want displayed (not case sensitive)
Details: set the details you want displayed (not case sensitive)
Event types: select the event types you want displayed
Event Log list:
Lists the events according to the filters used:
Event type
Severity
Name (filtered via Group)
Date
Time
IP
Details (sent to the software from the device)
Export to Excel Export the list of events to an excel file
Delete Selected Log Records Delete the selected lines (not available to the user)
Deselect All Records Clear selection
Select All Log Records Select all the lines
