Your VS-626 (VS-828) Video Audio Matrix Switcher
KRAMER: SIMPLE CREATIVE TECHNOLOGY
4
Control the
VS-626 (VS-828) using the front panel buttons, or remotely via
the Kramer
RC-IR2 Infra-Red Remote Control Transmitter, or via an
external remote IR receiver (optional), or via RS-232 or RS-485 serial
commands transmitted by a touch screen system, PC, or other serial controller
The
VS-626 (VS-828) is dependable, rugged and fits into two vertical spaces
(2U) of a standard 19" rack. To achieve the best performance:
Connect only good quality connection cables, thus avoiding
interference, deterioration in signal quality due to poor matching, and
elevated noise levels (often associated with low quality cables)
Avoid interference from neighboring electrical appliances and position your
Kramer
VS-626 (VS-828) away from moisture, excessive sunlight and dust
4 Your VS-626 (VS-828) Video Audio Matrix Switcher
Figure 1 illustrates the
VS-626 and Figure 2 illustrates the VS-828. Table 1 and
Table 2 define the front and rear panels of the
VS-626 (VS-828), respectively.
