Technical Specifications
19
8 Technical Specifications
Table 5 details the
VS-626 (VS-828) technical specifications
1
.
Table 5: Technical Specifications of the VS-626 / VS828
INPUTS:
VS-626
6 composite video 1Vpp/75 on BNC connectors
1 sync/video genlock with sync select switch
6 audio stereo up to +4dBm/62k on RCA connectors
VS-828
8 composite video 1Vpp/75 on BNC connectors
1 sync/video genlock with sync select switch
8 audio stereo up to +4dBm/62k on RCA connectors
OUTPUTS: VS-626
6 composite video 1Vpp/75 on BNC connectors
6 audio stereo +4dBm/50 on RCA connectors
VS-828
8 composite video 1Vpp/75 on BNC connectors
8 audio stereo +4dBm/50 on RCA connectors
MAX. OUTPUT LEVEL:
VIDEO: 2Vpp
AUDIO: 20Vpp
BANDWIDTH (-3dB):
VIDEO: 100MHz
AUDIO: 100kHz
DIFF. GAIN:
0.05%
DIFF. PHASE:
0.03 Deg.
K-FACTOR:
< 0.05%
S/N RATIO:
VIDEO: 74dB
AUDIO: 88 dB unweighted (1Vpp)
CROSSTALK (all hostile): VIDEO: -50 dB @5MHz
AUDIO: –71.4dB@1kHz
CONTROLS:
Manual, RS-232 or RS-485
COUPLING:
VIDEO: DC
AUDIO: AC
AUDIO THD + NOISE:
0.016% (1V, 1kHz)
AUDIO 2nd HARMONIC: 0.012%
POWER SOURCE:
230 VAC, 50/60Hz (115 VAC, USA)
DIMENSIONS:
19 inch (W), 7 inch (D), 2U (H) rack mountable
WEIGHT:
3.4kg. (7.5lbs.) approx.
ACCESSORIES:
Power cord, Null modem adapter, Windows®-based control software
OPTIONS:
External IR receiver
2
, extension cable
3
1 Specifications are subject to change without notice
2 15 meters long, P/N: 95-0104050
3 15 meters long, P/N: 95-0103050
