HOW DO I GET STARTED?

The fastest way to get started is to take your time and do everything right the first time. Taking 15 minutes

to read the manual may save you a few hours later. You don’t even have to read the whole manual. If a

section doesn’t apply to you, you don’t have to spend your time reading it.

4

UNPACKING AND CONTENTS

The items contained in your Kramer accessory package are listed below. Please save the original box and

packaging materials for possible future transportation and shipment.

Switcher

User Manual

Kramer Concise Product Catalog

12 V DC Power Supply

4 Rubber Feet

4.1 Optional Accessories

The following accessories, which are available from Kramer, can enhance implementation of your

switcher

. For information regarding cables and additional accessories, contact your Kramer dealer.

Rack Adapter (RK-50R) - Used to install smaller machines in a standard 1 or 2 U rack. One or

more machines may be installed on each adapter.

BNC "Y" Connector - Used for looping purposes and splits the incoming signal to enable

connection of an additional machine.

Termination Plug - Used to terminate the line to 75ohm for proper matching.

A video or s-Video distribution amplifier – such as the Kramer VM-3V, VM-50V, VM-10ARII,

VM-20ARII (video), VM-3S, VM-50YC, VM-5YC, VM-10YC (s-Video) for distributing the

output signals to several acceptors simultaneously.

An Audio Distribution Amplifier – such as Kramer VM-50A, VM-80A etc. for distributing the

output signals to several acceptors simultaneously.

A line amplifier – such as Kramer VM-9S, 104L (video), VM-9YC, 103YC (s-Video), for

transmitting signals over long distances, minimizing cable losses.

VIDEO TESTER - A new, unique, patented, indispensable tool for the video professional, the

Video Tester is used to test a video path leading to/from an amplifier. By pressing only one touch

switch it can trace missing signals, distinguish between good and jittery (VCR sourced) signals,

and identify the presence of good signals. Whenever a video signal is missing- because of bad

connections, cable breaks or faulty sources- the Video Tester is all you need.
