3
2
VS-55 VS-55A VS-55V VS-55YC
Configuration Dual 5x1 5x1 5x1 5x1
Inputs 5 dual signals, on
RCA connectors
5 stereo audio,
1Vpp/50 k on RCAs
5 Composite / single
Component,
1Vpp/75ohm on
BNCs
5 s-Video (Y/C)
1Vpp/75ohm (Y),
0.3Vpp/75ohm (C) on
4P connectors
Outputs 1 dual signal, on RCA
connectors
LINK connector
(DB9), EXT
connector (RCA)
1 stereo audio,
1Vpp/100 ohms on
RCAs
LINK connector
(DB9), EXT
connector (RCA)
1 Composite / single
Component,
1Vpp/75ohm on a
BNC
LINK connector
(DB9), EXT
connector (RCA)
1 s-Video (Y/C)
1Vpp/75ohm (Y),
0.3Vpp/75ohm (C) on
a 4P connector
LINK connector
(DB9), EXT
connector (RCA)
Switching
system
Electromechanical Electromechanical Electromechanical Electromechanical
Vertical
Interval
NO NO YES YES
Bandwidth 270 MHz 100 kHz 150 MHz 120 MHz (Y)
Control 5 front-panel touch
switches, remote
contact closure
5 front-panel touch
switches, remote
contact closure
5 front-panel touch
switches, remote
contact closure
5 front-panel touch
switches, remote
contact closure
DIFF. GAIN NA NA 0.88% 0.03%
DIFF. PHASE NA NA 0.35 Deg. 0.07 Deg.
THD NA <0.08% NA NA
S/N Ratio NA >78 dB >73 dB >78 dB (Y)
Max. Output Up to 60 V 3 Vpp / 100 ohm >1.6 Vpp/75 ohms 1.4 Vpp/75 ohms, (Y)
Accessories 12 V Power Supply 12 V Power Supply 12 V Power Supply 12 V Power Supply
Dimensions
(W, D, H)
16.5 x 12 x 4.5 (cm)
(6.5" x 4.7" x 1.8")
16.5 x 12 x 4.5 (cm)
(6.5" x 4.7" x 1.8")
16.5 x 12 x 4.5 (cm)
(6.5" x 4.7" x 1.8")
16.5 x 12 x 4.5 (cm)
(6.5" x 4.7" x 1.8")
Power Supply 12 VDC, 100 mA 12 VDC, 100 mA 12 VDC, 100 mA 12 VDC, 115 mA
Weight 0.62kg. (1.4 lbs.)
Approx.
0.62kg. (1.4 lbs.)
Approx.
0.66 kg. (1.46 lbs.)
Approx.
0.64 kg. (1.4 lbs.)
Approx.
