Technical Specifications

10 Technical Specifications

Table 12 includes the technical specifications:

Table 12: Technical Specifications

of the VS-3232Vxl Video Matrix Switcher

INPUTS:

32 composite video, 1Vpp / 75 on BNC connectors

OUTPUTS:

32 composite video, 1Vpp / 75 on BNC connectors

VIDEO BANDWIDTH:

500MHz, -3dB / >50MHz, 0.1dB

ALL HOSTILE CROSSTALK:

<-49dB @5MHz

NON LINEARITY

<0.1%

VIDEO S/N:

63dB unweighted / 70dB @5MHz weighted

DIFF. GAIN:

<0.05% / 0.8Vpp

DIFF. PHASE:

<0.03 Deg.

K-FACTOR:

<0.05%

CONTROL:

19 pushbutton switches; RS-232, RS-485, IR remote, Ethernet

COUPLING:

SWITCHING:

3 modes for Vertical interval switching and Immediate switching

DIMENSIONS:

19-inch (W), 7-inch (D) 2U (H) rack-mountable

POWER SOURCE:

230 VAC, 50/60Hz, (115VAC, U.S.A.) 10VA

WEIGHT:

3.5kg (7.8 lbs.) approx

ACCESSORIES:

Power cord, Null modem adapter, Windows®-based Kramer control

software, Windows®-based Ethernet Configuration Manager and Virtual

Serial Port Manager, Infra-red remote control transmitter

1 Specifications are subject to change without notice
