4 VS-21DPIR - Overview
3 Overview
The VS-21DPIR is a high quality switcher for DisplayPort (DP) signals that accepts
two DP inputs—letting you select either DP input using a switch located on the
panel—and routes the selected DP input signal to the DP output.
In particular, the VS-21DPIR features:
•
Uses up to four lanes at rates of 1.6Gbps or 2.7Gbps bandwidth per lane
•
Features a maximum resolution of 2560x1600 pixels and a total maximum
data rate of 10.8Gbps over four lanes
•
Is HDCP compliant and HDTV compatible
•
Passes the EDID signals from the display device to the source
•
Features high-resolution and rich colors, and the transport of audio and
multiple video streams
The VS-21DPIR is 5V DC fed and can be controlled remotely via the contact
closure REMOTE input select terminal block connector or the infrared remote
control transmitter.
3.1 Defining the VS-21DPIR 2x1 DisplayPort Switcher
This section defines the VS-21DPIR.
