Technical Specifications

6 Technical Specifications

Table 2 includes the technical specifications:

Table 2: Technical Specifications

of the VS-21B

INPUTS:

2 sets of composite video, each on a BNC connector, and 2 sets

of unbalanced stereo audio, each on RCA connectors, or

2 sets of component video (YUV) each on a BNC connector and

2 RCA connectors

OUTPUT:

1 set of composite video on a BNC connector, and unbalanced

stereo audio on RCA connectors, or

1 set of component video (YUV) on a BNC connector and 2

RCA connectors

BANDWIDTH (-3dB):

700MHz

DIFF. GAIN:

0.01%

DIFF. PHASE:

0.01°

K-FACTOR:

<0.05%

VIDEO S/N RATIO:

81dB

VIDEO CROSSTALK (all hostile): 51dB@5MHz
CONTROLS:

Channel selector via push button on front panel

SWITCHING SYSTEM:

Mechanical, “Break-before-make”

COUPLING:

AUDIO THD + NOISE:

0.085%

AUDIO 2nd HARMONIC:

0.005%

POWER SOURCE:

Not fed - mechanical

DIMENSIONS:

18.8cm x 10.2cm x 4.4cm (7.4" x 4" x 1.7"), W, D, H

WEIGHT:

0.64kg. (1.4lbs.) approx.

OPTIONS:

RK-81 19” Rack Adapter

1 Specifications are subject to change without notice
