1 Introduction
Welcome to Kramer Electronics (since 1981): a world of unique, creative and
affordable solutions to the infinite range of problems that confront the video,
audio and presentation professional on a daily basis. In recent years, we have
redesigned and upgraded most of our line, making the best even better! Our
500-plus different models now appear in 8 Groups
1
, which are clearly defined
by function. Congratulations on purchasing your VS-21B 2x1 Audio / Video /
Component Switcher. The Kramer VS-21B is ideal for:
Home cinema switching
Ultra high bandwidth signal switching
The package includes the following items:
VS-21B 2x1 Audio / Video / Component Switcher
This user manual
2
2 Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
Review the contents of this user manual
Use Kramer high performance high resolution cables
3
3 Overview
The high resolution VS-21B 2x1 Audio / Video / Component Switcher is a
desktop-sized, HDTV compatible, mechanical switcher. It can, for example,
be used as a 2x1 composite video and unbalanced stereo audio switcher, or as
a 2x1 component video switcher. In particular, the VS-21B:
Uses an “RF” PCB design with 3 ultra high bandwidth channels,
providing bandwidth of 700MHz, and is therefore suitable for use with
almost any common signal
Provides a simple solution for many switching needs and as the design is
passive, it does not need power, thus increasing its versatility
