Page 9
Control Software - Defining the Control Software
7
Main Window Features
#
Feature
Function
1
Menu Bar
Bar containing all the menus used for configuration and
control. For an explanation of all menus, see
Section 3.1
2 Command
Button
Tool Bar
Buttons used for saving and opening predefined setups,
connecting and disconnecting the device to be controlled
and selecting PIP settings. For an explanation of all
command buttons, see
Section 3.2
3
Input Switch Buttons
Click one of the 9 input buttons to select a main input. The
selected input button turns green, see
Note: The input switch button configuration is dependent
on the type of switcher connected
4
PIP Input Switch
Dropdown
Click to choose the source of the picture to insert in the
PIP display, see
Section 3.4
5
Output Volume Slider
Drag the slider up to increase the output volume; drag the
slider down to decrease the output volume. The volume
level is shown in the volume level indicator, feature 7, see
6
PIP Preview Window
This window shows how the PIP feature is configured
7 Volume
Level
Indicator
Shows the output volume numerically from -100 to +28
8
Mute Checkbox
Click this checkbox to turn off/on the output volume
9
Refresh Button
Rereads and reloads the present main Input settings
10
Input Properties
Dropdowns
The properties displayed depend on the input chosen, see
3.1
The Menu Bar
The following table describes the Control Software menu bar options.
Menu
Sub Menu 1
Sub Menu 2
Description
File
Open
Open an existing profile
Save
Saves the input label configuration
Exit
Exit the Control Software
Device
Connect/Disconnect
Connects or disconnects the controlled
device
Factory reset
Returns the device to its preset default
settings
Refresh
Refreshes the information on the screen
Panel Lock
Prevents tampering with the front panel
buttons. Settings: On/Off
Panel Save Lock
Select On or Off
Set to ON to save the lock status when
the machine is powered down
Panel Input Lock
Select On or Off
Set to OFF so you can still use the
SOURCE buttons on the front panel
even when the lock button is on
