Control Software - Operating the Control Software 13
5 Operating the Control Software
5.1 Switching an Input to an Output
To switch an input to the output:
•
Click on the required input switch button to activate it.
The input is selected and the button changes to green as shown in Figure 9 .
Figure 9: Input Selection
5.2 Using the Preset Display Configurations
The output display can be configured using the presets: full, PIP, P+P and split.
•
Full shows the full-screen display of the chosen Input Switch
•
PIP shows the full display of the chosen Input Switch with an inserted image
selected from the PIP Input Switch. The user can relocate the inserted image
by dragging the window and resize it by dragging the corner of the window
•
P+P shows the chosen Input Switch display side-by-side with the chosen
PIP Input Switch display. The displays are equal sized and do not cover the
full screen. They cannot be dragged or resized
