Control Software - Defining the Control Software 11
3.6 Input Properties
The following table describes the Input Properties frame.
Note: The fields displayed are dependent on the type of switcher
connected and the type of input chosen.
Switch Field 1 Field 2 Parameters
Input 1-4 Source Type -
Component H-position Sets the horizontal position of the
display:
0-1000
V-position Sets the vertical position of the
display: 0-1000
Phase Sets the input phase: 0-31
Source Type -
Y/C Video standard Sets the video standard: Auto,
NTSC, PAL
Source Type -
Video Video standard Sets the video standard: Auto,
NTSC, PAL
Input 5-6 UXGA1 H-position Sets the horizontal position of the
display:
0-1000
V-position Sets the vertical position of the
display: 0-1000
Frequency Sets the frequency for UXGA inputs:
0-50
Phase Sets the input phase: 0-31
Input 7-8 HDMI1 Color format Sets the color format: Auto, RGB,
YUV
HDMI switch
behavior Set to DVD/Normal or PC/Bypass
Set to Normal for sources with
HDCP. When in Normal operation,
the unit sends a hot plug to the
source for any Group/Scaler
switching request. There might be
some graphic cards that might shut
OFF the VGA/HDMI output following
the hot plug detection. To prevent
this, set this parameter to the Bypass
mode so the unit will not send a hot
plug for switching request (the hot
plug will be detected by the source
only when plugging a physical
connection)
HDMI Input HDCP Set to On or Off for each HDMI input
HDCP support can be enabled (On) or
disabled (Off) for each of the HDMI
inputs, allowing the source to transmit a
non-HDCP signal if required (for
example, when working with a Mac
computer)
Input 9 USB Slide show Sets the speed of the slide show:
Long, Max, Off
