4 SID-X1N - Overview
3 Overview
The SID-X1N accepts an HDMI, DisplayPort, DVI and PC graphics video input, as
well as an unbalanced stereo audio input (which is embedded into the output
signal), and transmits the signal via TP (Twisted Pair) cable to a compatible
switcher or DGKat receiver, (for example, the VP-81SIDN or PT-572+). The
device also provides an unbalanced, stereo audio output. When the SID-X1N is
connected to a switcher, it also controls the input and output selection of the
switcher.
In particular the SID-X1N: features:

HDTV support
 HDMI with x.v.Color™ and 3D

HDCP compliancy —works with sources that support HDCP repeater mode

Input signal detection based on video clock presence

Automatic input selection based on manual selection or last connected input

Automatic analog audio detection and embedding

Installation up to 50m (164ft) from the switcher, (30m with the TP-574)

I- EDIDPro™ Kramer Intelligent EDID Processing™ – Intelligent EDID
handling & processing algorithm ensures Plug and Play operation for HDMI
systems

A lockable EDID

Equalization and reclocking of the data

A maximum data rate of 4.95Gbps (1.65Gb per graphics channel)

Support for digital audio formats

A MegaTOOLS
®
sized enclosure. Two devices can be mounted in a rack
using the optional RK-T2B adapter
You can control the SID-X1N using the front panel buttons, or remotely via contact
closure switches.
