Technical Specifications
11
7 Technical Specifications
Table 4 includes the technical specifications
1
of the TP-210A:
Table 4: Technical Specifications of the TP-210A
INPUTS: 1 UXGA video on a 15-pin HD connector, 1 unbalanced stereo audio on a
3.5mm mini jack, 1 S/PDIF on an RCA connector, 1 RS-232 with 1 RxD line
on a terminal block connector.
OUTPUTS: 10 twisted pairs on RJ-45 connectors, 2 UXGA on 15-pin HD connectors, 2
unbalanced stereo audio on 3.5mm mini jacks, 2 S/PDIF on RCA connectors,
2 RS-232 with 2 TxD lines on terminal block connectors.
MAX. OUTPUT LEVEL: Video: 1.6V; Audio: 2.3V.
POWER OUTPUTS: 12V DC 0.5A max via each RJ-45 output (PINs 4, 5)
RESOLUTION: UXGA & 1080p
BANDWIDTH: 20Hz to 20kHz @1dB (audio)
SAMPLING RATE FOR S/PDIF: 48kHz
S/N RATIO: AUDIO: >75dB
TOTAL GAIN: AUDIO:
Analog/analog: 0dB
Analog/SPDIF: -12dBFS
TND+N: AUDIO: <0.02%
POWER SOURCE: 100-240V AC, 50/60 Hz, 46VA
DIMENSIONS: 19" x 9.3" x 1U (W, D, H) rack mountable
WEIGHT: 3kg (6.6lbs) approx.
ACCESSORIES: Power cord 2 , rack “ears”
1 Specifications are subject to change without notice
2 We recommend that you use only the power cord that is supplied with this machine
