KRAMER: SIMPLE CREATIVE TECHNOLOGY

Connecting the TP-210A

8

6

Connecting the TP-210A

This section describes how to connect the TP-210A (see section

6

), wire the

CAT 5 LINE OUT RJ-45 Connectors (see section

6.1

), and wire the RS-232

connectors (see section

6.1

).

To connect the TP-210A, as illustrated in

Figure 3

, do the following

1

:

1. Connect a UXGA source (for example, a laptop’s graphics card) to the

UXGA INPUT 15-pin HD connector.

2. Connect an analog

2

audio source to the Audio IN 3.5mm mini jack, for

example, using a Kramer C-GMA/GMA cable (VGA 15-pin HD +Audio
jack to VGA 15-pin HD +Audio jack)

3

, and press the S/PDIF – ANALOG

selector button.

3. Connect an RS-232 cable with a 9-pin D-sub connector at one end to the

laptop, and a 2-pin terminal block connector at the other end to the RS-232
IN port (G, Rx).

4. Connect the UXGA OUT 1 15-pin HD connector to the UXGA acceptor

(for example, a plasma display), and the ANALOG AUDIO

2

OUT 1

3.5mm mini jack connector to the analog audio connector on the acceptor. If
required, connect the RS-232 G and TX1 terminal block connector to the
RS-232 port on the acceptor.

5. Connect the UXGA OUT 2 15-pin HD connector to a UXGA acceptor (for

example, a display), and the ANALOG AUDIO

2

OUT 2 3.5mm mini jack

connector to the analog audio acceptor (for example, an AV Receiver).

6. Connect the LINE OUTPUT CAT 5 connectors as follows

4

:

ƒ The LINE OUT 1 RJ-45 connector on the TP-210A to the LINE IN

RJ-45 connector on a TP-124

5

unit via UTP cabling

6

(with a range

of up to 300ft (up to 100m))

7

ƒ The LINE OUT 10 RJ-45 connector on the TP-210A to the LINE

IN RJ-45 connector on another TP-124, via UTP cabling (with a
range of up to 300ft (up to 100m))

1 Switch OFF the power on each device before connecting it to your TP-210A. After connecting your TP-210A, switch on its

power and then switch on the power on each device

2 Alternatively, you can connect a digital audio source and acceptors and release the S/PDIF – ANALOG selector button

3 Not supplied. The full list of Kramer cables is on our Web site at

http://www.kramerelectronics.com

. You can also connect

a UXGA source to the UXGA IN 15-pin HD connector, and a separate audio source to the AUDIO IN 3.5mm mini jack

4 You do not have to connect all the outputs

5 Refer to the separate user manual, which can be downloaded at

http://www.kramerelectronics.com

6 For details of how to wire a CAT 5 LINE IN/LINE OUT RJ-45 connector, see section

6.1

7 Alternatively, you can connect the Kramer TP-46, which can be connected to an additional TP-46 unit for transmitting the

signal further
