Technical Specifications
11
6
Technical Specifications
Table 4 includes the technical specifications.
Table 4: VM-3AN Audio Distributor Technical Specifications
VM-3AN
VM-3SN
VM-3VN
INPUT:
1 balanced audio stereo
on 5-pin terminal blocks
1 YC on a 4-pin
connector
1 composite video on a
BNC connector
OUTPUTS:
3 balanced audio stereo
on 5-pin terminal blocks
3 YC on 4-pin
connectors
3 composite video on
BNC connectors
MAX. OUTPUT LEVEL: Audio: 18.5Vpp R+/-,
L+/- outputs
2Vpp, Y
1.8Vpp
BANDWIDTH (-3dB):
>100 kHz
135MHz
430MHz
DIFF GAIN:
–
0.03%
0.12%
DIFF PHASE:
–
0.03Deg
0.03Deg
K-FACTOR:
–
<0.05%
<0.05%
S/N RATIO:
90dB @1kHz
78dB @5MHz
74.3dB
CONTROL:
Output level control:
-77 to +6dB, R+/-, L+/-
channels
Y-level: -1.6 to +6.3dB;
C-level: -0.4 to +7.6dB
Level: -1.6 to +6dB;
Equalization: 0 to +6dB
COUPLING:
–
AC
AC
AUDIO THD + NOISE: 0.008%
–
–
AUDIO 2d HARMONIC: 0.001%
–
–
POWER SOURCE:
12V DC, 89mA
12V DC, 29mA
12V DC, 27mA
DIMENSIONS:
11.7cm x 6cm x 3.2cm (4.6” x 2.4” x 1.3”) W, D, H
WEIGHT:
0.28 kg (0.62 lbs.) approx.
ACCESSORIES:
Power supply
OPTIONS:
Rack adapter
