4 VM-1010, VM-1021, VN-1055, VM-54 - Your VM-1010
4 Your VM-1010
This section describes the VM-1010 Programmable Video Distributor.
4.1 Overview
The VM−1010 is a high−performance distribution amplifier for composite video. It
can also be configured as a 1:5 distribution amplifier for s−Video (Y/C) signals and
has controls to compensate for signal losses inherent in long cable runs.
The VM−1010 is designed for studio and other demanding applications. It has two
looping video inputs, each splitting to 5 outputs. The user may select 2x1:5 or 1:10
operation via front panel control switches. Several VM-1010 units may be chained
through the looping inputs. Output signals are DC or AC coupled (user selectable)
for maximum flexibility.
The unit features:
• High bandwidth of 235MHz (−3dB)
• Dual-mode configuration either as a 1:10 (composite) or a 1:5 (s−Video) DA
• Grouped level (gain) and EQ (peaking) controls
• A video AC/DC coupling selection
• Looping inputs
• Selectable input signal termination
• Standard 19” rack mount size of 1U
Figure 1 and Figure 2 define the unit.
