Technical Specifications
9
5 Technical Specifications
Table 4 includes the technical specifications:
Table 4: Technical Specifications
1
of the PT102A / PT102S / PT102VN
PT102A
PT102S
PT102VN
INPUTS:
1 audio stereo,
1Vpp/20k on a 3.5mm
mini plug connector
1 s-Video, 1Vpp /75 (Y),
0.3Vpp /75 (C), on a 4p
connector
1 Video, 1Vpp /75 on a
BNC connector
OUTPUTS:
2 audio stereo,
1Vpp/150 on 3.5mm
mini plug connectors
2 s-Video, 1Vpp /75 (Y),
0.3Vpp /75 (C), on a 4p
connectors
2 Video, 1Vpp /75 on
BNC connectors
MAX. OUTPUT LEVEL: 6 Vpp
2 Vpp
2 Vpp
BANDWIDTH (-3dB): 100 kHz
150 MHz
470 MHz
DIFF. GAIN:
Not applicable
< 0.03%
0.05%
DIFF. PHASE:
Not applicable
0.03 Deg.
0.05 Deg.
K-FACTOR:
Not applicable
<0.05%
<0.05%
S/N RATIO:
71.6dB
78dB
76dB
CONTROLS:
Gain: -50dB to +18.8dB Gain: -1.9dB to +4.9dB
(Y and C)
Gain: -1.2dB to +6dB,
EQ.: 0 to + 7.5dB, 50 MHz
COUPLING:
AC
AUDIO THD + NOISE: 0.017%, 1kHz
Not applicable
POWER SOURCE:
12VDC, 30mA
12VDC, 26mA
DIMENSIONS:
6 cm x 6.5 cm x 2.5 cm (2.36" x 2.56" x 1") W, D, H.
WEIGHT:
0.14 kg (0.31 lbs.) approx.
ACCESSORIES:
Power supply, mounting bracket
OPTIONS:
VA-50P 6 Port Universal 12-Volt Power Supply with 6 outlets
1 Specifications are subject to change without notice
