Installation: (Refer to Figure 1)
1. Place the Base (item #6) on a stable surface. Connect the two Vertical Support Rods
(items #7) by screwing them together.
2. Assemble the Vertical Support Rods into the Mounting hole in the Base. Secure to
base by using wrench provided to tighten nut.
3. Tighten the Support Clamp (item #8) to the upper end of the Vertical Support Rods.
4. Connect the Horizontal Holding Rod (item #9) to the Stirrer (item #1) by screwing into
threaded mounting hole located at the rear of the Stirrer. Then install the opposite end
of the Horizontal Holding Rod into the Support Clamp and tighten. The Stirrer can be
easily adjusted up / down, and in / out by carefully loosening and tightening the Support
Clamp.
5. When ready to use Stirrer - Install the Stirrer Propeller (item #5) by using the Chuck
Key provided to loosen and tighten the opening for the Chuck (item #4).
Operation: (Refer to Figure 1)
 Before testing or operating this Stirrer, please read all instructions carefully.
To ensure the running safety of the stirrer and personnel, be sure to inspect support
connections regularly.
The Stirrer should only be operated when installed on the Base. Hand held operation
is prohibited.
The Overhead Stirrer cannot be used in a flammable and/or explosive environment.
 Before plugging the power cord into the appropriate grounded electrical outlet, make
sure that the power switch (item #11) on the Stirrer is in the off position and the speed
control knob (item #13) is in the starting/slowest position.
1. A test run is recommended before use and the stirring propeller should not be installed
when testing.
2. After plugging the stirrer into the electrical outlet, turn on the power switch (item #11).
The power indicator lamp (item #10) will illuminate.
3. Slowly turn the speed control knob (item #13) clockwise to increase speed. The rpm
value in the digital display (item #12) will increase accordingly. Turning the speed
control knob counter-clockwise will decrease the speed.
