ASSEMBLY INSTRUCTIONS FOR

10L, 15L, & 20L UNJACKETED

PROCESS REACTOR SYSTEMS















New & Improved Open

Air Frame Design

Provides Excellent

Accessibility

6-Neck Lid with Large

Powder Addition Port

Lower Support Plate

has a V-Shaped

Opening Allowing an

Unobstructed View of

the Bottom Valve

Zero Dead Space

Detachable Drain Valve

has Knob with Laser

Etched Directional

Arrows for Open & Close

Electric or Air Motor.

Optional XP Motor

Available

Electric Motor has

Separate Controller

with Digital Display

Improved Support Clamp

Auto-Centers Reactor

and Lid Allowing Quick

Installation & Removal

of Reactor

Support Frame with

Oversized Rugged

S.S. Uprights and

Heavy Duty PTFE

Coated Aluminum

Fittings

Removable S.S. Pipe

Used for Supporting Side

Shelf and Manifold

Heavy Duty

Lockable Casters

Perfluoro O-Rings on

60mm & 200mm Flanges

PTFE Coated #304

S.S. Cooling Coil

Digital Temperature

Controller

Support Bushings for

Optional Safety Shield
