PLEASE KEEP THIS OPERATION MANUAL HANDY FOR FUTURE REFERENCE
Please check the components in the Packing list before installation
Packing list:
Item Description Qty. Item Description Qty.
Overhead Stirrer 1 Stirrer Propeller 1
Base 1 Chuck Key 1
Vertical Support Rods 2 Wrench 1
Horizontal Holding Rod 1 Operation Manual 1
Support Clamp 1
General Description:
Overhead stirrer with a digital display, two speed ranges (from 60-2000rpm), and mechanical
speed adjustment. Aluminum alloy body. Output stirring speeds and torque remain virtually
constant through IC controller speed detection technology. Complete unit comes with stirrer,
stand, clamp to attach stirrer, and a 4-blade propeller with a diameter of 50mm. 1 year
warranty.
Technical Data:
Rated Voltage (VAC): 120 ±10%
Rated Frequency (Hz): 50/60
Rated Torque (N-m): 0.52
Dimensions
– Including stand (WxDxH) (mm): 260 x 360 x 760
Total Shipping Weight (kg): 9.9
Permissible Ambient Temp. (C): 40
Permissible Relative Humidity (%): 90
Stirring Capacity (liters of water): 20
Maximum Viscosity (mPas): 10,000
Motor Rating Input (watts): 180
Motor Rating Output (watts): 120
Speed Range (low setting rpm): 60-500
Speed Range (high setting rpm): 240-2000
Chuck Range (mm): 5-10
