© MuxLab Inc. HDMI 4x4 Matrix Switch, HDBT Installation Guide
Page 7
3.
Installation Procedure
3.1. Parts List
The HDMI 4x4 Matrix Switch, HDBT (500416-POE) comes with the following parts:
• Base unit
• Four (4) IR Emitters
• One (1) IR Sensors
• One (1) 110-240V/24VDC, 5A Power Supply
• Power Cord (US, EU or UK)
• One (1) USB Type A - Type B Cable
• One (1) RS232 Cable
• One (1) Infrared remote
• One (1) Quick Reference Sheet
Please verify that all parts are present before proceeding.
