RMS Technologies Page 13 Version 1.21
R325 Single Axis Driver Manual 08/23/2007
9. COMMANDS (Page per Command Listing)
Protocol Syntax
Command Format: #
Example: #AHT1000
Sets the Hold Timeout for Driver A to 1000
To query a command use the following format
Query Format: #
Example: #AFR
Queries Driver A for the current Firmware Revision
The response would be in the following format
Response Format: *
*AFR325100
R325 firmware revision 1.00
stand for "Carriage Return" and "Line Feed" respectively. These are NOT
characters to be typed in. For direct keyboard users, these values are executed when
the "Return" key is pressed. For programmers, a "Carriage Return" and "Line
Feed" (also known as a "New Line") command needs to be executed after each
command.
Command
(Case Sensitive)
Operand Example Description
HT 100 -5000 #AHT100
Sets the Hold
Timeout to 100
mS Hold Timeout - Command or Query
Default = 5000
- Reads or sets the time interval in milliseconds after any
motor movement, before the motor current is changed from
Run Current to Hold Current.
PF 0 - 3 #ACD1
Sets Mixed
Mode damping
to 15% Percent Fast Decay - Command or Query
Default = 2
- Allows the Damping Mode of the driver IC to be set.
0 = Fast Decay
1 = Mixed Mode 15%
2 = Mixed Mode 48%
3 = 100%
The optimum setting will vary with motor inductance and
step rate; however the default ‘Mixed Mode’ setting will work
well with almost all motors.
FR - #AFR Firmware Revision - Query Only
- Returns 3 digit part code followed by 3 digit firmware
revision value.
Reply
*AFR325100 //R325 firmware revision 1.00
