Comfort-Aire PTHP15A130A User Manual
Page 2

THE FOLLOWING WARNINGS ARE
VERY IMPORTANT FOR SAFETY.
PLEASE READ THEM CAREFULLY
BEFORE INSTALLATION!
1. This air conditioner must be installed by a
certificated installer.
2. Please insure that there is an available ground in
the power supply system before installation.
3. To avoid electric shock or death, the socket
or terminal blocks for power supply to the air
conditioner(include 277V and 115V and 208-230V
series and the units that have LCDI power cord)
must have a Ground Fault Circuit Interrupter.
4. During installation, do not cross connect or reverse
L1 and neutral. Please be sure the ground wire is
firmly connected otherwise it is possible to result in
electrical shock or death.
RECOGNIZE THIS SYMBOL
AS A SAFETY PRECAUTION
WARNING
THE MANUFACTURER WILL NOT BE RESPONSIBLE
FOR ANY INJURY OR PROPERTY, DAMAGE
ARISING FROM IMPROPER SERVICE OR
SERVICE PROCEDURES. IF YOU INSTALL OR
PERFORM SERVICE ON THIS UNIT, YOU ASSUME
RESPONSIBILITY FOR ANY PERSONAL INJURY OR
PROPERTY DAMAGE WHICH MAY RESULT, MANY
JURISDICTIONS REQUIRE A LICENSE TO INSTALL
OR SERVICE HEATING AND AIR CONDITIONING
EQUIPMENT.
WARNING
HIGH VOLTAGE
DISCONNECT ALL POWER BEFORE
SERVICING OR INSTALLING THIS UNIT.
MULTIPLE POWER SOURCES MAY BE PRESENT,
FAILURE TO DO SO MAY CAUSE PROPERTY
DAMAGE, PERSONAL INJURY OR DEATH
PACKAGED TERMINAL A/C
OWNER’S MaNual
Heat Controller
1
CONTENTS
UNIT FEATURES ...................................................... 2
INSTALLATION INSTRUCTION ................................ 4
WIRING ..................................................................... 8
OPERATING INSTRUCTIONS
(Accessory Optional). ................................................ 9
MAINTENANCE AND CLEANING ............................11
NORMAL OPERATING SOUNDS
AND CONDITION .................................................... 13
DIAGNOSTIC CODES ............................................ 13
TROUBLE SHOOTING ........................................... 14
IMPORTANT NOTES:
Before using this manual, check the serial plate for
proper model identification.
The installation and servicing of this equipment must
be performed by qualified,experienced technicians
only.
Due to policy of continual product improvement, the
right is reserved to change specifications and design
without notice.
IMPORTANT NOTE TO THE OWNER
The service portion of this manual is to be used by
qualified,professionally trained HVAC technicians
only. The manufacturer does not assume any
responsibility for property damage or personal injury
for proper service procedures or services performed
by an unqualified person.
IMPORTANT NOTE TO THE SERVICER
Read this manual and familiarize yourself with the
specific items which must be adhered to before
attempting to service this unit. The precautions
listed in this Installation Manual are intended as
supplemental to existing practices. However, if there
is a direct conflict between existing practices and the
content of this manual, the precautions listed here
take precedence.
!
!
