13
AIRFLOW DATA
Table 6. Blower Performance Data
FMG36(****)F1E
Motor Speed 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8
Low 936 901 891 840 789 739 688 613
Med-Low 1,160 1,122 1,087 1,046 1,001 950 899 855
Medium 1,287 1,253 1,213 1,178 1,142 1,092 1,049 1,002
Med-High 1,434 1,394 1,353 1,328 1,297 1,248 1,220 1,202
High 1,550 1,515 1,495 1,457 1,429 1,416 1,388 1,355
FMG30(****)F1E
Motor Speed 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8
Low 869 832 795 758 704 639 579 507
Medium 933 903 866 820 770 714 640 576
High 1,014 971 929 884 833 780 714 640
FMG24(****)F1E
Motor Speed 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8
Low 846 795 756 707 668 589 533 467
High 926 890 845 791 732 672 603 536
FMG18(****)F1E
Motor Speed 0.1 0.2 0.3 0.4 0.5 0.6
Low 665 645 592 521 422 326
High 769 719 656 565 459 347
NOTES:
1) Airflow is shown in cfm, +/- 5%.
2) External static pressure is shown in inches W.C.
3) All airflows are measured with filter and with dry coil. For wet coil, subtract .1” external static pressure.
4) See unit nameplate or installation instructions for maximum recommended external static pressure.
Table 7. Control Board Operation
Control Signal
& MODE
Operation Total KW Board Action
W
(EHEAT)
ON
5 KW
Stage 1 Heat on instantly
Heat blower on after 3 second delay
8KW / 10 KW
Stage 1 Heat on instantly
Heat blower on after 3 second delay
Stage 2 Heat on after 5 seconds delay
OFF
Heat stages off instantly
Blower off after 15 second delay
W & Y
(AUX HEAT)
ON
5 KW
Stage 1 Heat on instantly
Cool blower on after 3 second delay
8KW / 10 KW
Stage 1 Heat on instantly
Cool blower on after 3 second delay
Stage 2 Heat on after 5 seconds delay
OFF
Heat stages off instantly
Heat blower turns off after 40 second delay
G
(FAN)
ON Cool blower on after 3 second delay
OFF Cool blower off instantly
Y
(H.P. & COOL)
ON Cool Blower on after 3 second delay
OFF Cool Blower off after 40 second delay
ELECTRICAL DATA & DIAGRAMS
