CONTROL REFERENCE GUIDE
9
Unit - (Front , Top, Left & Right Panel)
Left Right
TOP
FRONT
Headphone jack
Disc door
Screen
STD.BY/ON (standby/on) button
Turns the unit on and puts it in standby mode.
FUNCTION button
Select the source.
/ SKIP (TUNING) buttons
Press button once instantly to go back
to previous chapters / tracks. Press button
once instantly to advance a chapters / tracks.
Scan next or previous available radio stations.
VOLUME (+/-) buttons
Change the loudness of the sound from the
speakers connected to the unit.
STOP button
Stop playing a disc.
PLAY (PRESET) button
Press to start or resume playback.
Preset tuner memory up.
Display window
See Display system information (Page 11).
COLOR control
Adjust for color intensity.
SCREEN (OFF / WIDE / NORMAL) switch
WIDE : Wide-screen.
NORMAL : Pan screen.
PAUSE button
Press to pause playback of disc. Each time
you press the
PAUSE button the picture
advances one frame. Press the PLAY
button to resume playback.
REPEAT (BAND) button
Repeat chapter or title of a DVD.
Repeat single track or whole CD.
Switch between AM(MW) and FM frequency.
DISPLAY button
Change disc status information displayed on
the screen.
SUBTITLE button
Select one of the subtitle languages
programmed on a DVD.
STANDBY indicator
When the unit is turned on by pressing the
STD.BY/ON button. If you press the
STANDBY/ON button on the remote control,
the unit will turn off and go into standby
mode. The light will continue to illuminate.
Remote sensor
BRIGHTNESS control
Adjust the lightness or darkness of the color.
1) 9)
10)
12)
11)
2)
3)
4)
5)
6)
8)
7)
Note: Screen saver - If no button is pressed within a few minutes, the function will active. If you
want to return the normal screen, press any button.
(continued on next page)
