3
Winch Packing List .......................................................03
Safety Warnings & Precautions ....................................04
Winch Assembly & Mounting (2.0 Model) ....................09
Winch Assembly & Mounting (2.5 Model).....................10
• Mount Winch ......................................................10
• Mount Control Box ............................................11
• Mount Connector for Remote ...........................12
• Install Wiring ......................................................12
• Handlebar Switch Assembly .............................13
Check the System .........................................................14
Winch Maintenance ......................................................14
Replacing the Rope ......................................................14
Planning and Use of Your Winch ..................................15
Troubleshooting ............................................................17
Winch Assembly Drawing .............................................18
Winch Parts List ............................................................19
Specifications ................................................................20
Extreme Heavy Duty 2.0 ...............................................20
Extreme Heavy Duty 2.5 ...............................................21
Table of Contents:
DESCRIPTION QUANTITY
1. Winch Assembly with Wire Rope ...........................1
2. Cap Bolt M8 X 30 .......................................................2
3. Lock Washers ...........................................................2
4. Flat Washers ..............................................................2
5. M8 Nuts .....................................................................2
6. Mounting Plate ...........................................................1
7. Clevis Hook w/Pin ...................................................1
8. Power Cord/Switch Assembly .................................1
9. Strap ...........................................................................1
Winch Packing List
