20
Specifications
Extreme Heavy Duty 2.0
Specifications
Rated line pull: 2000lbs (907kgs) single line
Motor: Permanent magnetic DC 12V with
(1.1hp)/0.82kw output
Gear Train: Differential planetary
Gear Ratio: 153 : 1
Wire Rope: 4mm x 15.2m (5/32"x50')
Drum Size: 31.5mm x 72mm
Dimensions: 285mm x 105mm x 105mm
N.W: 6.5 kg (14.3 lbs)
G.W: 9.5 kg
Line speed and motor current (first layer)
Line pull and cable capacity
Line Pull
LBS 0 500 1000 1500 2000
KGS 0 227 454 680 907
Line Speed
FPM 10.5 9.2 7.5 5.2 2.9
MPM 3.2 2.8 2.3 1.6 0.9
Motor Current Amps 12 30 60 75 90
Layer of cable 1 2 3 4 5 6
Rated line pull
Per layer
LBS 2000 1630 1380 1190 1050 940
KGS 906 740 620 540 470 420
Cable capacity
Per layer
Ft. 6.5 14 23.5 35 47 50
M 2.0 4.3 7.2 10.6 14.4 15.2
