Rugged Ridge Dash Organizer Tray, 07-10 Jeep Wrangler (JK) User Manual
Page 1, Summary of installation, Page 1 of 4
13551.10 Rugged Ridge™ Dash Organizer instructions
2007 - up Jeep® JK Wrangler®
Dash top organizer for 2007 and up Jeep® JK Wrangler® (2DR, 4DR)
Page 1 of 4
PAGE 1
WARNING ! Reduce risk of serious injury in event of accident. Area above passenger side airbag
must be kept clear in order for airbag to properly deploy. Accessories or trays cannot
be mounted in this area. Do Not Remove tray stop bar. For on-road use, remove any
accessories that may dislodge or pose impact risk in event of accident.
16
9
10
3
4
13
2
14
15
19
11
8
20
12
18
17
7
5
1
6
Your Rugged Ridge™ Dash Organizer is intended as supplemental storage for the off-road
communication, navigation gear and accessories you need close at hand. As illustrated
below, trays and accessories securely mount to an aluminum bar attached via supplied brackets
to existing Jeep® dash mounts. No drilling is required. Review parts list and understand all
instructions and warnings prior to beginning installation.
Summary of Installation:
