Rugged Ridge Dual Battery Tray, 07-11 Jeep Wrangler (JK) User Manual
Page 4
Jeep
®
JK Wrangler Dual Battery Tray
Page 4 of 4
11214.53
Stock (-) cable to body
frame ground.
Stock (+) cable
to starter.
Factory cable to
fuse box
Main Battery
Main Battery
Factory (+) cable to
fuse box
Stock (+) cable
to starter
Stock (-) cable to
body frame ground
11.
The drawings below show how batteries may be connected for use with or without extra relay:
