Jeep, Jk wrangler dual battery tray – Rugged Ridge Dual Battery Tray, 07-11 Jeep Wrangler (JK) User Manual
Page 2
Jeep
®
JK Wrangler Dual Battery Tray
Page 2 of 4
11214.53
6.
Remove factory battery box by removing the 3 nuts that secure
the box to the fire wall and 4 bolts securing the box in the engine
compartment. Save this hardware. It will be used to install the dual
battery tray.
4.
Remove the power steering reservoir bolt and move the
reservoir to the side. Remove the reservoir mounting bracket and
set aside.
3.
Remove the EVAP solenoid connector and the power junction
connector. Slide the EVAP solenoid off the tab and move to the side.
5.
Release tabs that secure fuse box to hinged bracket and pull
fuse box upward. Lay fuse box over the side of the fender. Loosen the
bolt at the bottom of the battery that secures the battery to the factory
tray. Remove battery from vehicle.
