Martin Universal Design U-145N Avanti Master Studio Art Easel - Manual (Page 4)

Page 4
STEP 13. Attach Upper Canvas Support [G] to Easel by
sliding it downward from the top of the Center Column [A]
gliding it along the channel.
Secure at desired height by screwing in Wing Bolt [O] in
hole on front of Upper Canvas Support [G]. See FIG 13.
PLEASE NOTE: Loosen Wing bolt to move Upper
Canvas Support to desired position whenever
needed. Tighten Wing Bolt to secure.
FIG 13
A
G
O
STEP 14. Adjusting height Lower Canvas Support.
Insert finger in locking pin below Lower Canvas Support
and pull outward. This will cause the canvas support to
release from the metal ratchet column allowing you to raise
or lower the lower canvas support and center column.
FIG 14
PLEASE NOTE: Be careful when raising the canvas
support, that you are aware that the top of the
column will not interfere with ceiling or any other
object in rooms that have low ceilings.
Angle Adjustment:
Loosen wing nut on rear leg and tighten at desired angle.
Height Adjustment:
Unlock locking pin on lower canvas support, adjust to
desired height and release locking pin.
Easel should look like photo to right.
Martin/F. Weber Co. • 4444 Lawton Avenue, Detroit, MI 48208 USA
Tel:(313)895-0700 • Fax:(313)895-0709 • E-mail:[email protected]
www.MartinUniversalDesign.com • www.weberart.com
Made in China
MUD021006
If you have any problems with assembling this
easel, please call (313)895-0700 or e-mail us at
[email protected].
Thank You.
Enjoy your Easel!
