Minka Group F528-L-BS/CH - Manual (Page 14)

6
Step 1. (Fig 12) With the Canopy resting over the top Rodtie, raise the fan assembly and place the
Downrod Hanging Bracket inside the two arms in the Mounting Bracket and secure it with the
Philips Screw and Hex Nut provided. Note: If the fan is being hung on a slope ceiling, the longer of
the three rods should face the peak of the ceiling.
HANGING THE FAN
Fig. 12
MOUNTING
BRACKET
HANGING
BRACKET
PHILLIPS
SCREW
HEXNUT
