5
Step 1. (Fig. 10) Use the 1.5mm Allen Wrench to loosen the top and bottom Rod
ties from the Downrod Bridge Assembly and carefully slide both Rodties next to the Rod tie in the center, lightly re-tighten the Allen Set Screws
to keep them in place (do not over tighten the screws as this could scratch or damage the rod).
Step 2. (Fig. 10) Remove the three screws and "C"clips from the switch cup and save for later use.
Step 3. (Fig. 11) Bring the Downrod Bridge Assembly close to the Motor Switch Cup, firmly snap the White Wire Connector from the Downrod
Assembly to the White Wire Connector from the Switch Cup. Repeat this process with the Black Wire Connectors.
Step 4. (Fig. 11) Align the Reverse Switch Access Hole from the Coupling Cover Plate to the Reverse Switch in the Switch Cup. Place the Downrod
Assembly over the Switch Cup, making sure that all wire connections are tucked into the Switch Cup. Snap the "C" clips over the Switch Cup and
Coupling Cover Plate holes and secure with the three screws previously removed. Lower the Switch Cup Cover and secure it with the two Switch Cup
Cover screws provided.
INSTALLING THE DOWNBRIDGE
